Galvanized Steel Pipe

Pipe Type:Galvanzied welded steel pipe, galvanzied seamless steel pipe

Application: Used for transporting low pressure liquid, gas and heating.

Specification: Outside Diameter: 21.3mm ~ 406.4mm

                         Wall Thickness: 0.5mm ~ 20mm

                         LENGTH: 0.3mtr ~ 18mtr, Ramdon Length, Fixed Length, SRL, DRL

Standard and Grade: GB/T 3091 Q195/Q215/Q235/Q345,ASTM A53, BS 1387, JIS G3444 STK400/STK500, EN 39, EN 1139 S235JR/S275JR, EN 10025, EN 10219

Pipe Type: Seamless & Welded Steel Pipe (Round/Square/Rectangular)

End: Square Cut/Threaded, Burr Removed

Zinc Coating: 120~500 g/m2 (30um~70um)

Packing: Steel Strips bundled, Plastic Caps plugged, Waterproof Paper wrapped etc.

Contact us :

Email:info@sunrisesteelgroup.com

Whatsapp:+0086-13875806221

DescriptionProcessEquipmentDimension Inquiry

Galvanized steel pipe(galvanized pipe), Galvanised steel pipe(galvanised pipe)

Galvanized steel pipes are made of steel that has been covered with a layer of zinc metal. During the galvanizing process, we immerse the steel in a molten zinc bath, ensuring a tough, uniform barrier coating.


Application:

1.Building and structural material
2.Mechanical and general engineering purposes
3.Manufacturing of Bus Body, Railway Boogies
4.In Telephone department as Conduit Pipes

Types: Galvanzied welded steel pipe, galvanzied seamless steel pipe
Materials: Carbon steel
Connection type: threaded
Size range:1/8"-36"
Schedule: sch40, sch80, sch120, sch160, XH, XXH


Length of the galvanized tubes
- in diameter 4 - 16 mm 6000 + 100 mm
- in diameter 18 - 42 mm 6000 + 50 mm

Tolerances of the zinc coated tubes
- tolerances of the outside diameter:
- diameter between 4 - 30 mm ±0,08 mm
- diameter between 35 - 38 mm ±0,15 mm
- diameter up to 42 mm ±0,20 mm
- tolerances of the inside diameter are according to EN 10305-4
- tolerance of the wall thickness ± 10%

The Steel grades for the zinc coated tubes
E 235+N and E 355+N

Surface condition of the galvanized tubes
First layer – electrolitically leached zinc (Zn) – acts as anode and in a corrosive environment it corrodes first and the base metal is cathodically protected against corrosion. The zinc layer thickness may be in the range of 5 to 30 micrometers (µm).

Looking forward to your favourable inquiry!
